Barco ClickShare CX-50
Superior wireless conferencing tool
Introduction
ClickShare CX-50 is a wireless presentation and conferencing technology that allows users to start meetings with their preferred conferencing tool, providing an immersive conferencing experience in today’s BYOD trends. Automatically connecting to conference room audio-visual peripherals via USB, enhancing quality of interactions between people by freeing them from connecting devices, such as cameras or soundbars, in the conference room or boardroom.
Conferencing Button
You are able to enjoy a hassle-free meeting experience by automatically connecting devices of your choice in the room with ClickShare.
Collaboration App
It allows users to easily connect their devices with the meeting rooms’ hardware. A host of advanced features are available as well in this App, which is available on all devices, from desktop to Android and iOS.
Network Security
It allows full BYOD support for your own presentation devices, such as laptop, tablet and mobile. Meanwhile, network security will be greatly enhanced as no public presentation devices would be involved.
Specifications
ClickShare Base Unit dimensions
| Dimensions (HxWxD) | 39mm x 200mm x 202mm |
| Power supply | Standard 110/220 V AC plug |
| Power consumption | Operational: 50W (max) Standby: <8W (networked standby), < 0.5W (deep standby mode) |
| Weight | 900 gr |
General specifications
| Operating system | Windows 8/8.1/10. macOS 10.13 and higher. Android v9 and higher (ClickShare app). iOS 12 and higher (ClickShare app) |
| Video outputs | 4K UHD (3840*2160) @ 30Hz. HDMI 1.4b |
| Video inputs | 1920×1080 @30Hz. HDMI 1.4b |
| Audio output | USB, SPDIF, jack, HDMI |
| USB | 3 X USB-A, 1 X USB-C |
| Clickshare Buttons | 2 |
| ClickShare App | Desktop & Mobile |
| Native protocols | Airplay, Google Cast, Miracast |
| Noise Level | Max. 25dBA @ 0-30°C Max. 30dBA @ 30-40°C |
| Authentication protocol | WPA2-PSK in stand alone mode WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode |
| Wireless transmission protocol | IEEE 802.11 a/g/n/ac and IEEE 802.15.1 |
| Reach | Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit Frequency band 2.4 GHZ and 5 GHz (DFS) |
| Frequency band | 2.4 GHZ and 5 GHz (DFS channels supported in select number of countries) |
| Connections | 1x Ethernet LAN 1Gbit 1x USB Type-C 2.0 (back); 2x USB Type A 2.0 (back); 1x USB Type A 2.0 (front) Audio analog line out on mini jack socket (3.5mm), digital S/PDIF |
| Temperature range | Operating: 0°C to +40°C (+32°F to +104°F) Max: 35°C (95°F) at 3000m Storage: -20°C to +60°C (-4°F to +140°F) |
| Humidity | Storage: 0 to 90% relative humidity, non-condensing Operation: 0 to 85% relative humidity, non-condensing |
| Anti-theft system | Kensington lock |
| Certifications | FCC/CE |
| Touch screen support & Interactivity | Yes* |
| Room Dock (peripheral support) | High quality |
| Local view & moderation | High quality* |
| Network connection | LAN & WiFi (dual)* |
| Management and reporting | Yes |
| Warranty | 1 year standard. 5 years coverage via SmartCare |
* available in future firmware updates
